Advanced Pulse-Width-Modulation: With Freedom to Optimize Power Electronics Converters

This book is a technical publication for students, scholars and engineers in electrical engineering, focusing on the pulse-width-modulation (PWM) technologies in power electronics area. Based on an introduction of basic PWM principles this book analyzes three major challenges for PWM on system performance: power losses, voltage/current ripple and electromagnetic interference (EMI) noise, and the lack of utilization of control freedoms in conventional PWM technologies. Then, the model of PWM's impact on system performance is introduced, with the current ripple prediction method for voltage source converter as example. With the prediction model, two major advanced PWM methods are introduced: variable switching frequency PWM and phase-shift PWM, which can reduce the power losses and EMI for the system based on the prediction model. Furthermore, the advanced PWM can be applied in advanced topologies including multilevel converters and paralleled converters. With more control variables in the advanced topologies, performance of PWM can be further improved. Also, for the special problem for common-mode noise, this book introduces modified PWM method for reduction. Especially, the paralleled inverters with advanced PWM can achieve good performance for the common-mode noise reduction. Finally, the implementation of PWM technologies in hardware is introduced in the last part.

Dong Jiang received B.S and M.S degrees in Electrical Engineering from Tsinghua University in 2005 and 2007. He began his PhD study in Center for Power Electronics Systems (CPES) in Virginia Tech in 2007 and was transferred to University of Tennessee with his advisor in 2010. He received his PhD degree in University of Tennessee in Dec. 2011. He was with United Technologies Research Center (UTRC) in Connecticut as a Senior Research Scientist/Engineer from Jan 2012 to July 2015. He joined Huazhong University of Science and Technology as a professor in July 2015. Dong Jiang’s major research area is power electronics and motion control, with more than 30 published journal and conference papers and 9 patent applications in this area.
