Substrate Noise Coupling in RFICs (Analog Circuits and Signal Processing) - Softcover

Helmy, Ahmed; Ismail, Mohammed

Softcover

ISBN 10: 9048177898 ISBN 13: 9789048177899

Publisher: Springer, 2010

Synopsis

Substrate noise coupling in integrated circuits (ICs) is the process by which int- ference signals in the form of voltage and current glitches cause parasitic currents to ?ow in the silicon substrate to various parts of the IC. The source of such glitches and parasitic currents could be from the switching noise of high speed digital clocks on the same chip. In RF and mixed signal ICs the switching noise is coupled to sensitive analog and RF nodes in the IC causing degradation in performance that could severely impact the yield. Thus, overcoming substrate coupling is a key issue in successful “system on chip” ?rst-pass integration where RF and mixed signal blocks, high speed digital I/O interface are integrated with digital signal proce- ing algorithms on the same chip. This is particularly true as we move to sub-90 nanometer system on chip integration. In this book a substrate aware design ?ow is built, calibrated to silicon and used as part of the design and validation ?ows to uncover and ?x substrate coupling problems in RF ICs. The ?ow is used to develop a comprehensive RF substrate noise isolation design guide to be used by RF designers during the ?oor planning, circuit design and validation phases. This will allow designers to optimize the - sign, maximize noise isolation and protect sensitive analog/RF blocks from being degraded by substrate noise coupling.

About this title

About the Author

Mohammed Ismail is the Springer Series Advisor for the Analog Circuits and Signal Processing book series

From the Back Cover

Substrate Noise Coupling in RFICs addresses substrate noise coupling in RF and mixed signal ICs when used in a system on chip (SoC) containing digital ICs as well. This trend of integrating RF, mixed signal ICs with large digital ICs is found in many of today's commercial ICs such as single chip Wi-Fi or Bluetooth solutions and is expected to grow rapidly in the future. The book reports modeling and simulation techniques for substrate noise coupling effects in RFICs and introduces isolation structures and design guides to mitigate such effects with the ultimate goal of enhancing the yield of RF and mixed signal SoCs . This is particularly critical when process feature sizes scale down to the nano meter range.

Substrate Noise Coupling in RFICs reports silicon measurements, new test and noise isolation structures as well as calibration of a design flow used in the design and debug phases of RFICs. A design guide is articulated to be used by RFIC designers to maximize signal isolation and optimize chip floor plan, power and ground domains. Industrial examples of RFICs are given as demonstration vehicles to validate the proposed techniques. Some emphasis is put on the design of on-chip spiral inductors and the impact of the substrate on their performance. To our knowledge, this is the first title devoted to the topic of substrate noise coupling in RFICs as part of a large SoC.

Edition details

• Publisher: Springer
• Publication date: 2010
• ISBN 10: 9048177898
• ISBN 13: 9789048177899
• Binding: Paperback
• Language: English
• Number of pages: 134
